CD3500 BOAT LIFT WINCH
Price
Part Number
CD3500
CD3500 BOAT LIFT WINCH
FOR CHAIN DRIVE WINCH MODEL: CD3500
- A.....306292 - Reel Ass'y (+$66.74)
- B.....406215 - Spacer Shaft (+$4.62)
- C.....206745 - Set Screw, 1/4" (+$1.28)
- D.....206690 - Roller Chain, 54 Link (+$13.64)
- E.....206782 - Cap Screw, 3/8" x 1 (+$0.65)
- F.....206746 - Front Base Plate (+$39.73)
- G.....206788 - Cap Screw, 1/4" x 5 (+$1.09)
- H.....206779 - Flange Screw, 3/8" x 3/4 (+$1.06)
- J.....206784 - Hex Nut, 3/8", Brass (+$0.70)
- K.....406184 - Brake Cover (+$5.53)
- L.....206781 - Thread Forming Screw (+$0.83)
- M.....406171 - Ratchet Spacer (+$3.96)
- N.....204363 - Ratchet Spring (+$2.25)
- P.....404409 - Ratchet Pawl (+$3.77)
- Q.....205055 - Washer (+$0.62)
- R.....205270 - Lock Nut, 3/8" (+$0.62)
- S.....404408 - Ratchet Wheel (+$3.91)
- T.....306291 - Primary Shaft (+$25.28)
- U.....205123 - Pressure Plate (+$4.70)
- V.....406167 - Bearing Support Plate (+$10.19)
- W.....206372 - Bushing (+$2.89)
- X.....203963 - Roll Pin, 3/16" x 1-3/8" (+$0.47)
- Y.....406164 - Sprocket 10T (+$6.75)
- Z.....205139 - Washer 5/8" (+$0.78)
- AA....206686 - Bronze Flange Bushing (+$4.17)
- AB....406219 - Side Base Plate (+$10.35)
- AC....206780 - Lock Nut, 1/4" (+$0.18)
- AD....206747 - Back Base Plate (+$35.23)
- AE....406178 - Spacer, Long (+$4.08)
- AF....306245 - Sprocket Assy, 10T, 24T (+$28.12)
- AG....206689 - Roller Chain, 32 Link (+$5.90)
- AH....406216 - Spacer, Short (+$1.43)
- AJ....406221 - Top Cover (+$7.40)
- AK....206786 - Ratchet Bolt, 3/8" (+$0.78)
- AL....205118 - Cap Screw, 5/16" x 1/2" (+$0.86)
- AM....205119 - Washer, 5/16" (+$0.86)
- AN....206783 - Lock Washer, 3/8" (+$0.13)
Price
CD4000 BOAT LIFT WINCH
Price
Part Number
CD4000
CD4000 BOAT LIFT WINCH
For Chain Drive Winch Model: CD4000
- A.....306249 - REEL ASSY (+$126.11)
- B.....406169 - SHAFT (+$10.87)
- C.....206690 - ROLLER CHAIN, 54 LINK (+$13.64)
- D.....206697 - FRONT BASE PLATE (+$69.98)
- E.....406165 - SIDE BASE PLATE (+$63.86)
- F.....206698 - BACK BASE PLATE (+$69.98)
- G.....406166 - TOP COVER (+$21.33)
- H.....406180 - SPACER, 3/4" LONG (+$3.55)
- J.....306247 - SPROCKET ASSY, 24T,11T (+$31.77)
- K.....206689 - ROLLER CHAIN, 32 LINK (+$5.90)
- L.....406170 - SPACER SHAFT, 3/4" (+$11.40)
- M.....406179 - SPACER, SHORT, 3/4" (+$2.56)
- N.....205123 - BRAKE LINING PLATE (+$4.70)
- P.....404408 - RATCHET WHEEL (+$3.91)
- Q.....306275 - PRIMARY SHAFT (+$45.18)
- R.....406167 - BEARING SUPPORT (+$10.19)
- S.....206372 - BUSHING (+$2.89)
- T.....406164 - SPROCKET, 10T (+$6.75)
- U.....205139 - WASHER (+$0.78)
- V.....206686 - BRONZE BUSHING (+$4.17)
- X.....406171 - RATCHET SPACER (+$3.96)
- Y.....204363 - RATCHET SPRING (+$2.25)
- Z.....404409 - RATCHET PAWL (+$3.77)
- AA....205055 - FLAT WASHER (+$0.62)
- BB....205270 - LOCK NUT, 3/8" (+$0.62)
- CC....406178 - SPACER, LONG, 5/8" (+$4.08)
- DD....306245 - SPROCKET, 24T, 10T (+$28.12)
- EE....406177 - SPACER, SHORT, 5/8" (+$3.05)
- FF....205043 - BOLT, 3/8" X 1" (+$0.62)
- JJ....205050 - NUT, 3/8" (+$0.66)
- KK....204694 - LOCKNUT, 1/4" (+$0.24)
- LL....205391 - COVER SCREW (+$1.04)
- MM....406168 - CABLE CLAMP (+$11.80)
- NN....206682 - FLAT HEAD CAP SCREW (+$0.48)
- PP....205117 - ROLL PIN (+$0.66)
- QQ....205118 - BOLT, 5/16" (+$0.86)
- RR....205119 - WASHER (+$0.86)
- SS....406184 - BRAKE COVER (+$5.53)
Price
CD4500
Price
Part Number
CD4500
CD4500
For Chain Drive Winch Model: CD4500
- A.....306249 - REEL ASSY - CD4500 (+$126.11)
- B.....406169 - SPACER SHAFT, 5/8" (+$10.87)
- C.....206690 - ROLLER CHAIN, 54L - CD4500 (+$13.64)
- D.....206697 - FRONT BASE PLATE - CD4500 (+$69.98)
- E.....406165 - SIDE BASE PLATE - CD4500 (+$63.86)
- F.....206698 - BACK BASE PLATE - CD4500 (+$69.98)
- G.....406166 - TOP COVER (+$21.33)
- H.....406180 - SPACER (+$3.55)
- J.....306247 - SPROCKET ASSY, 24T, 11T (+$31.77)
- K.....206689 - ROLLER CHAIN, 32L (+$5.90)
- M.....406179 - SPACER (+$2.56)
- N.....205123 - PRESSURE PLATE (+$4.70)
- P.....404408 - RATCHET WHEEL (+$3.91)
- Q.....306275 - PRIMARY DRIVE SHAFT (+$45.18)
- R.....406167 - BEARING SUPPORT PLATE (+$10.19)
- S.....206372 - IRON BUSHING (+$2.89)
- T.....406164 - SPROCKET, 10T (+$6.75)
- U.....205139 - WASHER, 5/8" (+$0.78)
- V.....206686 - BRONZE BUSHING (+$4.17)
- W.....206786 - RATCHET BOLT, 3/8" (+$0.78)
- X.....406171 - RATCHET SPACER (+$3.96)
- Y.....204363 - RATCHET SPRING (+$2.25)
- Z.....404409 - RATCHET PAWL (+$3.77)
- AA....205055 - WASHER 3/8" (+$0.62)
- AB....205270 - LOCK NUT, 3/8" (+$0.62)
- AC....406178 - SPACER - CD4500 (+$4.08)
- AD....306245 - SPROCKET ASSY, 24T, 10T (+$28.12)
- AE....406177 - SPACER - CD4500 (+$3.05)
- AF....206782 - CAP SCREW, 3/8" X 1" (+$0.65)
- AG....206787 - CAP SCREW, 1/4" X 6" (+$1.25)
- AH....206779 - HEX FLANGE BOLT, 3/8" (+$1.06)
- AJ....206784 - BRASS NUT, 3/8" (+$0.70)
- AK....206780 - LOCK NUT, 1/4" (+$0.18)
- AL....206781 - COVER SCREW (+$0.83)
- AM....406168 - CABLE CLAMP (+$11.80)
- AN....206682 - FLAT HEAD CAP SCREW, 1/4" (+$0.48)
- AP....203963 - ROLL PIN (+$0.47)
- AQ....205118 - CAP SCREW, 5/16" (+$0.86)
- AR....205119 - WASHER, 5/16" (+$0.86)
- AS....406184 - BRAKE COVER (+$5.53)
- AT....206737 - ROLLER CHAIN, 38L (+$12.10)
- AV....206783 - LOCK WASHER, 3/8" (+$0.13)
Price
CD5500
Price
Part Number
CD5500
CD5500
For Chain Drive Winch Model: CD5500
- A.....306290 - REEL ASSY - CD5500 (+$182.78)
- B.....406169 - SPACER SHAFT, 5/8" (+$10.87)
- C.....206738 - ROLLER CHAIN, 46L - CD5500 (+$19.32)
- D.....206739 - FRONT BASE PLATE - CD5500 (+$99.49)
- E.....406213 - SIDE BASE PLATE - CD5500 (+$65.57)
- F.....206740 - BACK BASE PLATE - CD5500 (+$94.34)
- G.....406166 - TOP COVER (+$21.33)
- H.....406180 - SPACER (+$3.55)
- J.....306247 - SPROCKET ASSY, 24T, 11T (+$31.77)
- K.....206689 - ROLLER CHAIN, 32L (+$5.90)
- L.....406170 - SPACER SHAFT, 3/4" (+$11.40)
- M.....406179 - SPACER (+$2.56)
- N.....205123 - PRESSURE PLATE (+$4.70)
- P.....404408 - RATCHET WHEEL (+$3.91)
- Q.....306275 - PRIMARY DRIVE SHAFT (+$45.18)
- R.....406167 - BEARING SUPPORT PLATE (+$10.19)
- S.....206372 - IRON BUSHING (+$2.89)
- T.....406164 - SPROCKET, 10T (+$6.75)
- U.....205139 - WASHER, 5/8" (+$0.78)
- V.....206686 - BRONZE BUSHING (+$4.17)
- W.....206786 - RATCHET BOLT, 3/8" (+$0.78)
- X.....406171 - RATCHET SPACER (+$3.96)
- Y.....204363 - RATCHET SPRING (+$2.25)
- Z.....404409 - RATCHET PAWL (+$3.77)
- AA....205055 - WASHER, 3/8" (+$0.62)
- AB....205270 - LOCK NUT, 3/8" (+$0.62)
- AC....406212 - SPACER - CD5500 (+$4.08)
- AD....306245 - SPROCKET ASSY, 24T, 10T (+$28.12)
- AE....406211 - SPACER - CD5500 (+$3.91)
- AF....206782 - CAP SCREW, 3/8" X 1" (+$0.65)
- AG....206787 - CAP SCREW, 1/4" X 6" (+$1.25)
- AH....206779 - HEX FLANGE BOLT, 3/8" (+$1.06)
- AJ....206784 - BRASS NUT, 3/8" (+$0.70)
- AK....206780 - LOCK NUT, 1/4" (+$0.18)
- AL....206781 - COVER SCREW (+$0.83)
- AM....406168 - CABLE CLAMP (+$11.80)
- AN....206682 - FLAT HEAD CAP SCREW, 1/4" (+$0.48)
- AP....203963 - ROLL PIN (+$0.47)
- AQ....205118 - CAP SCREW, 5/16" (+$0.86)
- AR....205119 - WASHER, 5/16" (+$0.86)
- AS....406184 - BRAKE COVER (+$5.53)
- AT....306297 - SPROCKET ASSY, 28T, 10T (+$53.35)
- AU....206737 - ROLLER CHAIN, 38L (+$12.10)
- AV....206783 - LOCK WASHER, 3/8" (+$0.13)
Price
CD7000
Price
Part Number
CD7000
CD7000
For Chain Drive Winch Model: CD7000
- A.....306290 - REEL ASSY (+$182.78)
- B.....406169 - SPACER SHAFT, 5/8" (+$10.87)
- C.....206738 - ROLLER CHAIN, 46L (+$19.32)
- D.....206838 - FRONT BASE PLATE (+$50.02)
- E.....406269 - SIDE BASE PLATE (+$36.88)
- F.....206839 - BACK BASE PLATE (+$47.54)
- G.....406166 - TOP COVER (+$21.33)
- H.....406180 - SPACER (+$3.55)
- J.....306297 - SPROCKET ASSY, 28T, 10T (+$53.35)
- K.....206737 - ROLLER CHAIN, 39 LINK (+$12.10)
- L.....406170 - SPACER SHAFT, 3/4" (+$11.40)
- M.....406179 - SPACER (+$2.56)
- N.....205123 - PRESSURE PLATE (+$4.70)
- P.....404408 - RATCHET WHEEL (+$3.91)
- Q.....306275 - PRIMARY DRIVE SHAFT (+$45.18)
- R.....406167 - BEARING SUPPORT PLATE (+$10.19)
- S.....206372 - IRON BUSHING (+$2.89)
- T.....406164 - SPROCKET, 10T (+$6.75)
- U.....205139 - WASHER, 5/8" (+$0.78)
- V.....206686 - BRONZE BUSHING (+$4.17)
- W.....206786 - CAP SCREW, 3/8, 1-1/4" (+$0.78)
- X.....406171 - RATCHET SPACER (+$3.96)
- Y.....204363 - RATCHET SPRING (+$2.25)
- Z.....404409 - RATCHET PAWL (+$3.77)
- AA....205055 - WASHER, 3/8" (+$0.62)
- AB....205270 - LOCK NUT, 3/8" (+$0.62)
- AC....406212 - SPACER (+$4.08)
- AD....306346 - SPROCKET ASSY, 32T, 11T (+$33.12)
- AE....406211 - SPACER (+$3.91)
- AF....206782 - CAP SCREW, 3/8, 1" (+$0.65)
- AG....206787 - CAP SCREW, 1/4, 6" (+$1.25)
- AH....206779 - HEX FLANGE BOLT, 3/8" (+$1.06)
- AJ....206784 - BRASS NUT, 3/8" (+$0.70)
- AK....206780 - LOCK NUT, 1/4" (+$0.18)
- AL....206781 - COVER SCREW (+$0.83)
- AM....406168 - CABLE CLAMP (+$11.80)
- AN....206682 - FLAT HEAD CAP SCREW, 1/4" (+$0.48)
- AP....203963 - ROLL PIN (+$0.47)
- AQ....205118 - CAP SCREW, 5/16, 1/2" (+$0.86)
- AR....205119 - WASHER, 5/16" (+$0.86)
- AS....406184 - BRAKE COVER (+$5.53)
- AT....206783 - LOCK WASHER, 3/8" (+$0.13)
Price
SA5000AC & SA7000AC w/o Clutch
(W & W/O REMOTE)
Price
Part Number
D-SA5000AC-2
SA5000AC & SA7000AC w/o Clutch
(W & W/O REMOTE)
For Electric Winch Models: SA5000AC, SA5015AC, SA7000AC, SA7015AC - LESS CLUTCH SA7015AC, SA7015AC-CSA LESS CLUTCH
- A.....205191 - Retaining Ring (2) (+$0.66)
- B.....204012 - Bushing (+$1.54)
- C.....304813 - Drive Shaft Ass'y. (+$11.40)
- D.....204009 - Bushing (+$1.54)
- E.....204703 - 56T Gear (+$21.50)
- F.....304412 - Handle Ass'y. (+$9.99)
- G.....404557 - Base Spacer (+$3.71)
- H.....404922 - Base (+$27.98)
- K.....5703210 - Brake Spring Replacement Kit (+$13.24)
- N.....205192 - Locknut, 7/16-20 (+$1.26)
- P.....404535 - CLUTCH STUD (NO CLUTCH) (+$6.11)
- T.....204360-PL - SPACER WASHER (6) (+$0.62)
- U.....304414 - GEAR ASSY, 120T (+$58.19)
- X.....205015 - LOCKNUT, 1/2-20 (+$0.88)
- Y.....404562 - Front Plate Spacer (3) (+$1.54)
- Z.....404553 - Front Plate (+$15.90)
- AA....205238 - Screw-1/4-20x5/8 (3) (+$0.66)
- AB....205193 - Locknut, 10-32 (2) (+$0.78)
- AC....304407 - Brake Disc Ass'y. (+$19.32)
- AD....404522 - Motor Pinion (+$4.33)
- AE....205135 - 'E' Ring (+$0.56)
- AF....404559 - Reel Shaft (+$4.45)
- AG....204468 - Retaining Ring (+$0.86)
- AH....205337 - Screw, 1/4-20x3/8 (2) (+$0.56)
- AJ....304617 - Cable Clamp Kit (+$2.51)
- AK....205338 - Screw, 1/4-20x3/4 (2) (+$0.38)
- AL....304812 - Reel Ass'y. (+$40.44)
- AN....204713 - Cover Plug (+$0.86)
- AP....404637 - COVER (SA5000AC/SA7000AC) (+$29.89)
- AP....404638 - COVER (SA5015AC/SA7015AC) FOR REMOTE (+$29.89)
- AU....5240692 - CABLE & HOOK- 3/16"X20' (SA5000AC/SA5015AC) (+$26.99)
- AU....5240445 - CABLE & HOOK- 3/16"X50' (SA7000AC/SA7015AC) (+$41.99)
- AV....205190 - SCREW, 1/4-20X1" (2) (+$0.86)
- AW....206628 - TOP DECAL (NOT SHOWN) (+$12.57)
- CA....304921 - Motor Ass'y. (+$172.91)
- CB....204912 - Strain Relief Bushing (+$0.75)
- CC....205038 - Cord (+$15.30)
- CC....5240189 - GFCI CORD SET (OPTIONAL) (+$73.99)
- CD....204419 - SWITCH (SA5000AC/SA7000AC) (+$22.55)
- CE....205180 - Cap Screw (+$0.86)
- CF....304426 - Bridge Ass'y. (+$20.90)
- CG....205194 - Washer (+$0.48)
- CH....205195 - Hex Nut, 8-32 (+$0.66)
- DA....5240528 - PULLEY BLOCK & HOOK (SA7000AC & SA9000AC) (+$78.99)
- EA....5240890 - 6349 DUAL SWITCH REMOTE ASS'Y(SA5015AC/SA7015AC) (+$94.99)
- EA....5240528 - SINGLE SWITCH REMOTE ASS'Y (+$78.99)
- EA....204491 - IN-OUT ROCKER SWITCH ONLY (DUAL SWITCH REMOTE) (+$26.24)
- EA....204490 - OFF-RUN ROCKER SWITCH ONLY (DUAL SWITCH REMOTE) (+$26.24)
- EA....206435 - OUT/IN ROCKER SWITCH ONLY (SINGLE SWITCH REMOTE) (+$21.49)
- EB....206670 - STRAIN RELIEF BUSHING (+$0.44)
Price
DL1100A
(2000 - PRESENT)
Price
Part Number
DL1100A
DL1100A
(2000 - PRESENT)
For Pulling Winch Model: DL1100A
- B.....204006 - Bushing (+$1.54)
- C.....205012 - E-Ring (+$0.58)
- E.....5703046 - Handle - 7", with nut and decal (+$13.99)
- E.....5703657 - Handle - 6", with nut and decal (+$15.29)
- E.....5703442 - Handle - 5", with decal (+$16.09)
- F.....205015 - Handle Nut, 1/2"-20 Locknut (+$0.88)
- J.....205270 - Locknut (+$0.62)
- L.....5704531 - Ratchet Repair Kit (+$7.99)
- Q.....404876-BK - Base - DL1100A Painted Black (+$12.17)
- R.....304716 - Drive Shaft - DL1100A (+$9.88)
- T.....205144 - Reel Bolt - DL1100A (+$0.95)
- U.....206072 - Spacer - DL1100A (+$0.66)
- W.....5243506 - Rope Clamp Kit (+$2.99)
- Y.....304717-BK - Reel - DL1100A Painted Black, 7/8" Hub (+$26.74)
- Y.....304717-PL - Reel - DL1100A Zinc Plated, 7/8" Hub (+$27.56)
Price
DL1300A
(2000 - PRESENT)
Price
Part Number
DL1300A
DL1300A
(2000 - PRESENT)
For Pulling Winch Model: DL1300A
- B.....204006 - BUSHING (+$1.54)
- C.....205012 - E-RING (+$0.58)
- E.....5703046 - HANDLE - 7", WITH NUT & DECAL (+$13.99)
- E.....5703657 - HANDLE - 6", WITH NUT & DECAL (+$15.29)
- E.....5703442 - HANDLE - 5", WITH NUT & DECAL (+$16.09)
- F.....205015 - HANDLE NUT, 1/2-20 LOCKNUT (+$0.88)
- J.....205270 - LOCKNUT (+$0.62)
- L.....5704531 - RATCHET REPAIR KIT (+$7.99)
- R.....304722 - DRIVE SHAFT - DL1300A (+$12.65)
- S.....204007 - BUSHING (+$1.54)
- T.....203161 - REEL BOLT (+$1.54)
- U.....204807 - SPACER (+$0.97)
- W.....5243506 - ROPE CLAMP KIT (+$2.99)
- Y.....304723-BK - REEL - DL1300A PAINTED BLACK, 7/8" HUB (+$30.05)
- Y.....304723-PL - REEL - DL1300A ZINC PLATED, 7/8" HUB (+$30.05)
- Y.....306062-BK - REEL - DL1300A PAINTED BLACK, 1-7/8" HUB OPTIONAL (+$32.15)
- Y.....306062-PL - REEL - DL1300A ZINC PLATED, 1-7/8" HUB OPTIONAL (+$32.15)
- Z.....5153689 - HAND WINCH COVER - DL1300A OPT. (+$10.93)
Price
«
Previous
1
2
3
4
5
6
7
8
9
10...
Next
»
Our Products
Couplers & Coupler Balls
» Couplers & Accessories
» Coupler Balls
Fencing Tools
Fuel Tank Filters
Oil Cans
» Heavy Duty Pump Oilers
» Industrial Pump Oilers
» Pistol Pump Oilers
» Spray Tip Oilers
» Spring Bottom Oilers
» Spouts
Tongue Jacks
» Accessories and Parts
» Ag-Industrial Jacks
» Marine Jacks
Trailer Accessories & Roller Bunks
» Accessories
» Roller Bunks
Wheel Bearings & Protectors
Winches
» Brake Winches
» Hand Winch Accessories
» Electric Winches
» Electric Winch Accessories
» Pulling Winches
» Worm Gear Winches
Repair Parts
» Brake Winches - Repair Parts
» Electric Winches - Repair Parts
» Pulling Winches - Repair Parts
» Tongue Jacks - Repair Parts
» Worm Gear Winches - Repair Parts
Deals
